有懂閥門技術英文用語的來幫幫忙

這還不容易么 看我的翻譯 如果可以你就采納我的答案噢~~~！！

Titanium Valves: 1. General shall not, without permission Party casting welding repair process. 2. Material forged titanium material shall be ASTM B381 Gr. F2, or Gr. F3. Casting titanium material shall be ASTM B367 Gr. C2, or Gr. C3. Titanium components, the maximum iron content of 0.07% and the maximum hydrogen capacity of 60ppm. Casting the mechanical properties of casting residue to comply with ASTM requirements. Stick Titanium Standard ASTM B348 Gr.5. 3. X-ray detection casting is subject to 100% X-ray detection test, based on ASTM E446 Class A, B, C 2-class standards, with no D, E, F. 4. Penetrant testing all the casting in the stress test carried out after the required 100% of the permeability test, in order to avoid casting the cracks, trachoma and so on. 5. Certificate B must provide a detailed mechanical performance testing, physical testing, chemical composition of reports and documents. ? Hastelloy alloy valve 1. Castings Hastelloy Castings Hastelloy C4 and the need to use ASTM A494 Grade CW-2M of the alloy, the largest iron content does not exceed 2%. If you specify the use of Hastelloy C276, Ze Xu using UNS N10276 alloy, mechanical properties required to meet the ASTM minimum requirements. 2. X-ray detection for each casting is subject to ultrasonic or X-ray detection. After each batch and then take 10% of the testing, the nominal diameter greater than or equal 6 "of the body in need of complete testing, greater than or equal 8" in key parts of the body just for testing. -Ray flaw detection test based on ASTM E446 Class A, B, C 2-class standards, with no D, E, F. If you have casting did not meet testing standards be admitted to the batch number of the additional testing. If these two happen again does not meet state testing standards, then take all of the batch for testing. 3. Penetrant testing a batch of each supplier is required to provide penetration testing report at the same time need to provide mechanical tests, physical tests and chemical composition of reports. 4. Certificate B must provide a detailed mechanical performance testing, physical testing, chemical composition of reports and documents. ? dual-phase steel valves: 1. A dual-phase steel all of the components required to meet the ASME V111, Div 1, Appendix 7 requirements. 2. Material Duplex steel castings for example, to comply with ASTM A995 Grade 4A for 2205 alloy, grade 6A for the 2507 alloy. Chemical composition, mechanical properties to meet the requirements of subparagraphs 3 to 5. 3. Chemical composition of the amount of corrosion-resistant duplex steel (PREN) according to the formula: PREN = (Cr wt% + 3.3 Mo wt% + 16 N wt%), calculate the value of not less than the following. 2205 Alloy - 34 2507 Alloy - 40 4. Chemical composition requirements are as follows Material 2205 Alloy 2507 Alloy maximum carbon content of 0.030% 0.030% chromium content of 21.5-23% 24-26% nickel content of 4.5-6.5% 5.5-8.0% Mo content of 2.9 -3.5% nitrogen content of 0.145-0.2% 3.6-4.0% 0.24-0.35% maximum sulfur content of 0.02% 0.02% maximum phosphorus content of 0.03% 0.03% maximum silicon content of 1.0% 0.8% maximum manganese content of 2.0% 1.5% tungsten content of 0.5% maximum 0.8% maximum copper content of 0.5% 0.75% 5. mechanical properties requirements are as follows Material 2205 alloy 2507 alloy minimum tensile strength of 620MPa 700MPa 0.2% deformation deflection (minimum) 450 MPa 550MPa Elongation (2in%) 25min 15min maximum stiffness of 290 BHN (30.5 Rc) 310 BFN 6. The remaining test casting heat treatment, the need to use samples of the following tests. Testing methods and the use of the standard details of the Party should be provided. Tension Test ? ? ? Impact Test hardness testing ? corrosion testing 7. Non-destructive testing, after the final heat treatment in accordance with the following annotation can be seen in non-destructive testing penetration testing X-ray detection range of 100% 100% testing a key component of the valve based on ANSI B16 .34 standard ASME VIII Div 1 App 8 ASME VIII Div 1 App 7 processes ASME VIII Div 1 App 8 ASME VIII Div 1 App 7 acceptance ASME VIII Div 1 App 8 ASME VIII Div 1 App 7

可以吧

ASTMB367Gr.C2是什么材質

ASTM B367-93(2004) 鈦和鈦合金鑄件 Standard Specification for Titanium and Titanium Alloy Castings

C2是什么材料

SA-556M C2是ASME SA-556M標準中的管式給水加熱器用碳錳鋼珠光體型鋼，分為直管與規定須彎成“U”型的管子。此鋼號與我國GB5310中的20MnG、25MnG比較接近。

q235b是什么材質的鋼材

q235b是碳鋼材質。

Q235B是碳鋼的一種代號，表示屈服點為235MPa的B級碳素結構鋼。其化學成分主要是碳、硅、錳、硫、磷、鉻、鎳、銅等。具有一定的伸長率、強度，良好的韌性和鑄造性，易于沖壓和焊接。

用途廣泛，大部分用于焊接、鉚接或栓接的鋼結構件。常軋制成盤條或圓鋼、方鋼、扁鋼、角鋼、工字鋼、槽鋼等鋼材，中厚鋼板。用以制作鋼筋或建造廠房房架、高壓輸電鐵塔、橋梁、車輛、鍋 爐、容器、船舶等，也大量用作對性能要求不太高的機械零件。

由Q+數字+質量等級符號+脫氧方法符號組成。它的鋼號冠以“Q”，代表鋼材的屈服點，后面的數字表示屈服點數值，單位是MPa例如Q235表示屈服點為235 MPa的碳素結構鋼。

Q235A和Q235B的材質區分

主要在鋼材的含碳量方面，材質為Q235A的鋼材含碳量在0.14-0.22%之間，Q235B的鋼材含碳量在0.12-0.20%之間；在拉伸及沖擊實驗方面，材質為Q235A的鋼材不做沖擊實驗，材質為Q235B的鋼材做常溫沖擊試驗，V型缺口。
